ORANGE PI PC H3 QUAD-CORE LEARNING DEVELOPMENT BOARD

Products > Development Board > ORANGE PI PC H3 QUAD-CORE LEARNING DEVELOPMENT BOARD
    • 1
    • 2
    • 3
    • 4
    • 5

ORANGE PI PC H3 QUAD-CORE LEARNING DEVELOPMENT BOARD

shared：
Model Number
ORANGE PI PC H3
CPU
Cortex-A7 quad core for H3 ARM
GPU
Mali400MP2 GPU @ 600MHZ Supports OpengGL ES 2.0
Memory
1 GB DDR3 (shared with GPU)
On board storage
TF card (maximum 64GB)/MMC card slot
On board network
 10/100M Ethernet RJ45
Video input
Camera module with CSI interface
Video output
HDMI
Power supply
DC input, MicroUSB (OTG) cannot be used as power input USB2.0 Port: 1 USB2.0 HOST, 1 USB2.OTG
Compatible with Raspberry Pi
Low level pearls40pin connector
LED lights
Power indicator light and status indicator light
Supported operating systems
such as Android4.4, Ubuntu, Debian, etc
