RFID card reader module RC522 serial port reader 13.56mhz IC card RF module development board

shared：
RFID card reader module RC522 serial port reader 13.56mhz IC card RF module development board

Product Description

Product model: RC522 Sleep current:<80uA Peak current:<30mA Working frequency: 13.56MHz Card reading distance: 0-45mm Interface: UART TTL Baud rate: 115200 Data transmission rate: limited to 10Mbit/s Environmental working temperature: -20-80 degrees Celsius Storage temperature: -40-85 degrees Celsius Humidity: Relative humidity 5% -95% Protocol: Compliant with ISO14443A standard, supports S50, S70
