Smart Electronics Shenzhen PCB, PCBA Cloning , PCB Manufacture and Assembly

Smart Electronics Shenzhen PCB, PCBA Cloning , PCB Manufacture and Assembly
shared：
PCB Capacities and Technical Specification
Order Quantity
1-500,000
Layer
1, 2, 4, 6, up to 24 layer
Material
FR-4, High Tg, Isola, Aluminum, Rogers, etc
PCB type
Rigid, flexible, rigid-flexible
Shape
Rectangular, round, slots, cutouts, complex, irregular
Max PCB dimensions
1200mm*600mm
Thickness
0.2~4.0mm, Flex 0.01~0.25''
Thickness tolerance
± 10%
Copper thickness
0.5-6 oz
Copper thickness tolerance
± 0.25oz
Surface finish
HASL, LF HASL, Imm Gold, Imm Silver, OSP etc
Solder mask
Green, red, white, yellow, blue, black, orange, purple
Silk screen
White, black
Silk screen min line width
0.006'' or 0.15mm
Min drill hole diameter
0.01'', 0.1mm or 10 mil
Min trace/gap
0.075mm or 3mil
PCB cutting
Shear, V-score, tab-routed
PCBA Capacities and Technical Specification
PCBA
PCB+components sourcing+assembly+package
Assembly details
SMT and Thru-hole, ISO SMT and DIP lines
Lead Time
Prototype : 15 work days. Mass order : 20~25 work days
Testing on products
Testing jig/mold , X-ray Inspection, AOI Test, Functional test
Quantity
Min quantity : 1pcs. Prototype, small order, mass order, all OK
Files needed
PCB : Gerber files(CAM, PCB, PCBDOC)
Components : Bill of Materials(BOM list)
Assembly : Pick-N-Place file
PCB Panel Size
Min size : 0.25*0.25 inches(6*6mm)
Max size : 1200*600mm
Components details
Passive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component package
Cut Tape, Tube, Reels, Loose Parts
PCB+ assembly process
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing
Our Service
Electronic Engineering; PCB Manufacturing; Turnkey PCBA; PCB Clone; SMT; Component Sourcing; PCB Assembly; Plugin Assembly; PCBA Clone, PCB Packing Ect.
Main Product Applacation
Household Appliance; Medical Products; Communication Products; Network Device; Gate Way Control; Automotive Products; Industrial
Products; Consumer Electronics; Aviation; Renewable Energy Ect.
Certificate
CE; RoHS; ISO9001;FCC;EPR_Germany_WEEE;EPR_France_WEEE
1. If you need to custom PCB and PCBA , please check below information
2 . If you need to clone pcba ,please check below information

If this product doesn't meet your expectations, please also communicate with

us as we believe our expertise can assist you!

Q1: MOQ? Can I just buy 1 piece?

A1: We have a wide range of products, and the MOQ varies from product to product.The MOQ for customized circuit

boards is 5pcs. For other products,actually,there is no MOQ in Smart. We are able to handle small as well as large

volume production with flexibility. 1 piecs is OK ,as long as you can accept the sample price.


Q2: What is your Lead time?

A2: Lead time is usually punctual here, usually 5-10 days for sample, 10-15 days for mass production. For some

special situation,we can also advise customer in advance to avoid any inexpectation or loss at customer side.


Q3: What's the best price you can offer?

A3: It depends on the quantity you order. The more quantity ordered, the more favorable the price will be.

Both new and existing customers will enjoy corresponding discounts.Anything can be negotiated, so feel

free to consult us if you have any questions.


Q4: Besides this product, what other products can you offer?

A4: We offer one-stop service for PCB/PCBA/FPC/Clone boards/stencil/membrane switch and complete

components sourcing( Modules, Cable, Sensors, NTC, Aluminum heatsink, Water block,Copper tube,LCD,

LED,Switches and Connectors etc.) with a wide range, good quality and reasonable prices according to your need.


Q5: Do you have any relevant certificates for this product?

A5: Yes. We have CE ,ROHS and ISO9001:2015 certificates for PCBs/PCBAs/Membrane Switches. As for other products,

we can provide certificate authentication services. If you need them, please contact our salesperson.

Thank you for all your supports !  Welcome to contact us .
